Specs
Open Water Thrust
340lbf (155kgf) @ 10 kn, 480lbf (218kgf) @ 5kn
Input
12.5kw input power
Voltage options between 72vdc - 330vdc
RS485 digital speed control
Weight
105-145lbs (48-66kg) in air
79-119lbs (36-54kg) in water
(Depending on configuration
Depth Rating
2,300ft (700m) with 1 atm housings.
Full ocean depth when oil filled
(PBOF with remote electronics)
Construction
Available with hard anodized 6061-T6 aluminum.
Type 316 stainless steel or 6Al4V titanium housings.
Product Features
Tecnadyne’s brushless DC AUV thrusters use the same reliable features but with a focus on high efficiency. Each design has an option for direct drive motors to produce less noise.
- Brushless DC motor for maximum performance and longevity
- Magnetically coupled propeller drive eliminates all rotating shaft seals for optimum reliability
- Compound planetary gearbox and high rpm motor allows for a compact design
- Propeller designed for increased efficiency at various speeds
- Voltage options between 48 and 330vdc
- Self-contained electronics up to 1500m
